As the best China YDJ-6300 Heavy-Duty Hydraulic Baling Shear supplier,Jiangyin Tianfu Technology Co.,Ltd. provides quality YDJ-6300 Heavy-Duty Hydraulic Baling Shear to global clients

Video
  • Description
  • Technical Specifications
  • Scene

Features

  • Hydraulic drive,manual valve operation,or automatic running by remote control induction It makes dense bales also shears the scraps. It may compress and cuts big size scraps with its huge feeding box . Capacity is between 5 to 30 ton /hour. No-contact sensors to avoid re-calibration.

Structure

  • Strong Body for Heavy Duty
  • Original Hardox anti-wear plates
  • High quality heavy duty cylinders (Hardened and chrom-coated piston rots ,  speacial honed pipes)
  • The best quality brands are used in hydraulic and electronic parts
  • Hydraulic unit design producing high force with low consumption

List of the materials to process

  • Fe, Al, Cu, Cr-Ni Scraps
  • Ferrous and non-ferrous
  • Aluminium Extrusions
  • Sheet and plates
  • Mixed Scrap

List of the factories may need

  • Scrap Yards
  • Casting Plants

1

Shearing cylinder

Type

YG560/400-750

Stroke

750MM

Nominal thrust force

6300KN

Q’ty

1set

2

Main pressing cylinder

Type

YG280/180-650

Stroke

650MM

Nominal thrust force

1600KN

Q’ty

1set

3

Side pressing cylinder

Type

YG250/160-1500

Stroke

1500MM

Nominal thrust force

1250KN×2

Q’ty

2sets

4

Lid cylinder

Type

YG250/160-1928

Stroke

1928MM

Nominal thrust force

1250KN×2

Q’ty

2sets

5

Material push cylinder

Type

YG250/180-5150

Stroke

5150MM

Nominal thrust force

1250KN

Q’ty

1set

6

Compression room(L*W*H)

5200×2000×800 MM

7

Bale size (L*W*H)

5000×500×500 MM

8

Hydraulic working pressure

25MPa

9

Power

220KW

10

Voltage

380/3PH, 50Hz

11

Blade length

700MM

13

Motor

Type

Y280M-6

Power

55KW

Rated Rev.

970R/Min

Q’ty

4sets

14

Hydraulic Pump

Type

250YCY14-1B

Rated pressure

31.5 MPa

Rated outflow

250 ml/r

Q’ty

4sets
